ESTISURF® Emulsifiers

Emulsifiers for Solvents, Oils & Waxes

The ESTISURF® product range consist of surfactants for a wide range of applications in formulated chemical products. An important part of our ESTISURF® range is the emulsifiers for solvents, oil & waxes.

On this site, you will find our range of nonionic emulsifiers for application as primary or -secondary emulsifiers in release agents, polishes, solvent emulsions, metalworking lubricants etc.

In addition to emulsify oils & waxes, ESTISURF® emulsifiers can be used for making oils & solvents rinsible with water.

ESTISURF emulsifiers – a broad range for all applications

The selection of an emulsifier for a specific formulation depends on the required properties for the formulation but especially on the chemical nature of the medium to be emulsified.

Some oily components are highly polar whereas others are non-polar, and they require completely different emulsifiers to obtain a stable emulsion with a small droplet size. ESTI CHEM has experience with various types of emulsifiers creating stable, semi-stable or fast-splitting emulsions.

Often a combination of emulsifiers is applied, eventually additions of a wetting agents and co-solvents such as a small amount of glycol ethers.

Emulsifiers for a broad range of applications and formulations
ESTISURF® nonionic emulsifiers contribute to the formulation of cleaning agents

Parameters for emulsifier selection

 Some typical parameters, that influence the choice of emulsifier:

  • The pH value of the formulation: in the pH range 6-9, all emulsifiers may be applied, but the further the formulation goes to the acidic or alkaline side, the more we recommend focusing on fatty alcohol alkoxylates. For water-free formulations, there are no limitations.
  • The HLB value of the nonionic surfactant: a hydrocarbon solvent normally requires a lower HLB value of the emulsifier than more polar fluids such as esters. The table will guid you to the right selection of emulsifier for a screening test.
  • Requirements for raw material origin: for some applications, there may be requirements for bio-based origin of the formulation raw materials; in others it may no be important. Please consult www.estichem.com for more information about the content of bio-based raw materials in our products.
  • Requirements for Eco-label: In case you require eco-label on the formulation ingredients, you can consult estichem.com for further information about the eco-label qualifications of the various ESTISURF® emulsifiers.
  • Requirements for CLP label: you can find more information about the CLP labelling of an ESTISURF® emulsifier in the product MSDS.

Emulsifiers recommendations tabel

Please find below a table with recommendations of emulsifiers for various types of the oily phase. The recommendations are based on experience from practical work with the development of formulations for chemical products.

Product

Rapeseed oil

Paraffinic mineral oil

Hydro-carbon solvents

Mono-esters

Silicone oil

Montan ester wax

PE wax

ESTISURF 430 (*)















ESTISURF 480















ESTISURF 600















ESTISURF 950















ESTISURF 965















ESTISURF 970















ESTISURF 990















ESTISURF 1618/3















ESTISURF 1618/7















ESTISURF BA 1206















ESTISURF BA 1209















ESTISURF CO 40















ESTISURF RE 100















ESTISURF M27















(*): ESTISURF 430 can act as a low-HLB emulsifier, but most often it is applied as coupling agent to secure good solubility of the emulsifier in the oily phase.

Highly recommended

Recommended

Not recommended

ESTISURF® emulsifiers – a broad range for all applications

The selection of an emulsifier for a specific formulation depends on the required properties for the formulation but especially on the chemical nature of the medium to be emulsified.

Some oily components are highly polar whereas others are non-polar, and they require completely different emulsifiers to obtain a stable emulsion with a small droplet size. ESTI CHEM has experience with various types of emulsifiers creating stable, semi-stable or fast-splitting emulsions.

Often a combination of emulsifiers is applied, eventually additions of a wetting agents and co-solvents such as a small amount of glycol ethers.

ESTI CHEM offers a wide selection of emulsifiers with very different physical-chemical properties:

Product

Product type

HLB value

Active content (%)

Polarity

CLP classification

ESTISURF 430

Fatty acid ester

4.7

100

Low

None

ESTISURF 480

Fatty acid ester

7.4

100

Low

None

ESTISURF 600

Fatty acid ester

10.2

100

Medium

None

ESTISURF 950

Fatty acid ester

8.6

100

Low

None

ESTISURF 965

Fatty acid ester

10.0

96

Medium

None

ESTISURF 970

Fatty acid ester

11.0

100

Medium

None

ESTISURF 990

Fatty acid ester

14.0

100

High

None

ESTISURF 1618/3

Fatty alcohol alkoxylate

9.0

100

Low

None

ESTISURF 1618/7

Fatty alcohol alkoxylate

11.0

100

Medium

None

ESTISURF BA 1206

Fatty alcohol alkoxylate

12.3

90

High

H318

ESTISURF BA 1209

Fatty alcohol alkoxylate

13.8

90

High

H302, H318

ESTISURF CO 40

Fatty acid ester

13.6

100

High

None

ESTISURF RE 100

Fatty acid ester

7.0

100

Low

None

ESTISURF M27

Optimized emulsifier package

9.3

99

Medium

None
